| Herkunftsort: | CHINA |
| Markenname: | Brando |
| Zertifizierung: | CE |
| Modellnummer: | 2S200-20 |
| Min Bestellmenge: | 1 PC |
|---|---|
| Verpackung Informationen: | innere Kästen, Kartone, Paletten |
| Lieferzeit: | 7 Werktage |
| Zahlungsbedingungen: | L/C, T/T, Western Union |
| Versorgungsmaterial-Fähigkeit: | 100000 PC pro Monat |
| VENTIL-REIHE: | Reihe 2S | REF. NUMBER: | UNI-D Art SUW-20 |
|---|---|---|---|
| Spannung: | AC110V AV220V DC24V | Aktion: | Versuchsmembran |
| Hafen-Größe: | 3/4" Zoll | Medien: | Wasser-Luft-Gas |
| Flüssiges Viscossity: | Unterhalb CST 20 | Energie: | Magnet |
| Körper-Material: | Edelstahl | Membranmaterial: | NBR, FKM und EPDM |
| Markieren: | 2S200-20 Magnetventil,SUW-20 Magnetventil,Uni-Dart SUW-20 |
||
2S200-20 SUW-20 3/4'' Pilot Operated Water SS304 Solenoid Valve
2S200-20 is an electromagnetic valve, stainless steel, appropriate is used in the field of circulation time longer control, adopting direct acting diaphragm structure, the body is made of stainless steel, corrosion resistant function.It adopts a diaphragm structure and has the characteristics of quick opening and closing, stable performance, convenient use, high reliability and long service life. The water-using solenoid valve has strong anti-pollution ability. It can be used for a long time in rivers, rivers, lakes, oceans and various artificial waters.
2S200-20
2S:2 Position 2 Way Direct Drive Solenoid Valve With Stainless Steel Body.
200: The Aperture of Flow Rate is 20 mm
20: The Port Size is G 3/4 ''
Technical Data of 2W & 2S Solenoid Valve:
|
2W Series
|
2W025-08
|
2W040-10
|
2W160-15
|
2W200-20
|
2W250-25
|
2W350-35
|
2W400-40
|
2W500-50
|
|
2S Series
|
2S025-08
|
2S040-10
|
2S160-15
|
2S200-20
|
2S250-25
|
2S350-35
|
2S400-40
|
2S500-50
|
|
Orifice Size
|
2.5
|
4
|
15
|
20
|
25
|
35
|
40
|
50
|
|
Port Size
|
1/4''
|
3/8''
|
1/2''
|
3/4''
|
1''
|
1-1/4''
|
1-1/2''
|
2''
|
|
Medium
|
Water, Air, Gas, Oil
|
|||||||
|
Action
|
Direct Acting
|
Semi-Direct Diaphragm Operated
|
||||||
|
Function
|
2 Way, Normally Closed
|
|||||||
|
Fluid Viscosity
|
20 CST below
|
|||||||
|
Pressure
Range
|
0 to 1.0 Mpa
|
|||||||
|
Temp. Range
|
-5 to +85℃
|
|||||||
Main dimension of 2W & 2S Series Solenoid Valves:
|
2S Series
|
2W Series
|
A
|
B
|
C
|
D
|
E
|
|
2S025-06
|
2W025-06
|
64.5
|
30
|
75
|
43
|
1/8''
|
|
2S025-08
|
2W025-08
|
64.5
|
30
|
75
|
43
|
1/4''
|
|
2S040-10
|
2W040-10
|
70.6
|
32
|
82.4
|
53
|
3/8''
|
|
2S160-10
|
2W160-10
|
101.5
|
57
|
117
|
69
|
3/8''
|
|
2S160-15
|
2W160-15
|
101.5
|
57
|
117
|
69
|
1/2''
|
|
2S200-20
|
2W200-20
|
107
|
57
|
123.5
|
73
|
3/4''
|
|
2S250-25
|
2W250-25
|
111.5
|
73.5
|
134.5
|
99
|
1''
|
|
2S350-35
|
2W350-35
|
142
|
95
|
172
|
123
|
1-1/4''
|
|
2S400-40
|
2W400-40
|
142
|
95
|
172
|
123
|
1-1/2''
|
|
2S500-50
|
2W500-50
|
172
|
123
|
209
|
168
|
2''
|
Stainless steel solenoid valve characteristics:
1) The protection grade for this series solenoid valve is IP67.
2) These valves are made of stainless steel and can work in corrosive environments.
3) Pressure unit: 1kgf/cm2=1bar=0.1MPa=100KPa=14.5psi
4) The working temperature for Viton or PTFE can reach -20℃~169℃.
5) Different thread types can be offered according to customers' requirements, e.g.: G, PT, NPT etc.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
