Herkunftsort: | Ningbo, China |
Markenname: | BRANDO |
Zertifizierung: | CE, ISO |
Modellnummer: | BC-12-3 |
Min Bestellmenge: | 1pc |
---|---|
Preis: | Verhandlungsfähig |
Verpackung Informationen: | Schachtel, Karton, Palette |
Lieferzeit: | 4 bis 7 Arbeitstage |
Zahlungsbedingungen: | T/T, PayPal, Western Union |
Versorgungsmaterial-Fähigkeit: | 5000 Stück pro Monat |
Produktbezeichnung: | Pulskontroller | Kanalnummer: | 12 |
---|---|---|---|
Eingangsspannung: | 220Vac | Ausgangsspannung: | 24VDC |
Breite des Pulsens: | 00,01 bis 99,99 Sekunden | Pulsintervall: | 1 bis 9999 |
Zyklusintervall: | 1 bis 9999 | Anwendung: | Staubkollektor |
Hervorheben: | 12 Channels Pulse Controller,Dust Collector Pulse Timer,Pulse Jet Controller |
Dust Collector Pulse Valve Timer Controller 12 Channels 220VAC Input 24VDC Output
Pulse Controller is a pulse jet bag filter control device in cleaning system, its output signal to control Pulse Jet Valve, blow compressed air bag sequential cleaning, so dust remains in the design within a predetermined range, in order to protect the processing power and dust collecting effect.
1. Channel Number: the number of pulse valves in the equipment (off-line mode is the number of pulse valves in a single chamber);
2. Pulse Width: the working time of the pulse valve (blowing time);
3. Pulse Interval: the interval between 2 pulse valves;
4. Cycle Interval: the interval between the end of one cycle and the start of the next cycle;
Technical Data:
Model No | BC-08 | BC-10 | BC-12 | BC-16 | BC-20 | BC-24 | BC-30 | BC-36 | BC-52 | BC-64 |
Channel No | 8 | 10 | 12 | 16 | 20 | 24 | 30 | 36 | 52 | 64 |
Input Voltage | 24VDC, 110VAC, 220VAC, other can be customized | |||||||||
Output Voltage | 24VDC, 24VAC, 110VAC, 220VAC, other can be customized | |||||||||
Pulse Width | 0.1 to 999.9 Seconds | |||||||||
Pulse Interval | 1 to 9999 Seconds | |||||||||
Cycle Interval | 1 to 9999 Seconds | |||||||||
Working Environment | 1. -25°C to +55°C 2. The relative humidity of the air does not exceed 85% 3. No serious corrosion gas and conductive dust 4. No violent vibration or shock |
Detailed Images:
Controller Setting:
Controller Wiring:
Our Production:
Related Products:
![]() |
![]() |
![]() |
![]() |
Pulse Valve | Solenoid Coil | Solenoid Armature | Diaphragm |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
