Name: 1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 19.13BAS
Price: 26.00 USD
Availability: InStock

Startseite Produkte Edelstahl-Magnetventil

1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar

Produktdetails:

Herkunftsort:	NINGBO, CHINA
Markenname:	BRANDO
Zertifizierung:	CE, ISO
Modellnummer:	19.13BAS

Zahlung und Versand AGB:

Min Bestellmenge:	50 Stück
Preis:	Verhandlungsfähig
Verpackung Informationen:	Box, Karton, Palette
Lieferzeit:	7 Werktage
Zahlungsbedingungen:	T/T, Paypal, Western Union
Versorgungsmaterial-Fähigkeit:	200000 Prozent pro Monat

Kontakt

Ausführliche Produkt-Beschreibung

Produktname:	Magnetventil	Portgröße:	1/8 '', 1/4 ''
Öffnungsgröße:	1.2mm, 1.5mm, 2mm, 2.5mm, 2.8mm	Körpermaterial:	Edelstahl 304
Dichtungsmaterial:	NBR (Standard), EPDM, FKM (optional)	Funktionsmedien:	Luft, Wasser, Dampf, Gas, Flüssigkeit, Leichtöl usw.
Medientemperatur:	NBR (-10 bis +80°C), EPDM (-30 bis +120°C), FKM (-30 bis +150°C)	Arbeitsdruck:	0 bis 30 bar
Betrieb:	Direktwirkung des Plungers	Funktion:	2 Weisen-normalerweise offene
Stromspannung:	12VDC, 24VDC, 24 VAC, 110 VAC, 220 VAC
Hervorheben:	Normally Open Stainless Steel Solenoid Valve , 1/8'' Stainless Steel Solenoid Valve , 2 Way NO Solenoid Valve

1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar

This is a small and compact solenoid valve, 1/8'' or 1/4'' port, 1.2 to 2.8mm orifice, 0 to 30 bar, plunger direct acting, 2 way normally open, stainless steel 304 body, NBR standard seal, can be customized as EPDM or FKM seal to suit different working mediums, various voltages for your choice, such as 12VDC, 24VDC, 24VAC, 110VAC and 220VAC, etc. It is used for a wide arrange of industrial applications to control fluids.

Technical Data:

Model No	Port Size (inch)	Orifice Size (mm)	Cv	Working Pressure (bar)		Body	Seal	Voltage
Model No	Port Size (inch)	Orifice Size (mm)	Cv	DC	AC	Body	Seal	Voltage
2 Way Normally Closed, Direct Acting
19.13BAX012BXX	1/8'' 1/4''	1.2	0.09	0 to 30	0 to 30	Brass SS304	NBR EPDM FKM	12VDC 24VDC 24VAC 110VAC 220VAC
19.13BAX015BXX		1.5	0.11	0 to 30	0 to 30
19.13BAX020BXX		2.0	0.15	0 to 20	0 to 15
19.13BAX025BXX		2.5	0.18	0 to 14	0 to 10
19.13BAX028BXX		2.8	0.25	0 to 10	0 to 8
2 Way Normally Open, Direct Acting
19.13BBX012KXX	1/8'' 1/4''	1.2	0.09	0 to 10	0 to 10	Brass SS304	NBR EPDM FKM	12VDC 24VDC 24VAC 110VAC 220VAC
19.13BBX015KXX		1.5	0.11	0 to 9	0 to 9
19.13BBX020KXX		2.0	0.15	0 to 6	0 to 6
19.13BBX025KXX		2.5	0.18	0 to 4	0 to 4
19.13BBX028KXX		2.8	0.25	0 to 3	0 to 3
