Name: FDF6A FDF6A58 Sanhua Type Solenoid Valve FDF NC Series Valve For Heat Pump
Brand: Ningbo Brando Hardware Co., Ltd
SKU: FDF6A
Price: 65.00 USD
Availability: InStock

Startseite Produkte Abkühlungs-Magnetventil

FDF6A FDF6A58 Sanhua Type Solenoid Valve FDF NC Series Valve For Heat Pump

Produktdetails:

Herkunftsort:	China
Markenname:	BRANDO
Zertifizierung:	None
Modellnummer:	FDF6A

Zahlung und Versand AGB:

Min Bestellmenge:	5 Stück
Preis:	Verhandlungsfähig
Verpackung Informationen:	Innenkarton, Karton, Palette
Lieferzeit:	Verhandlung
Zahlungsbedingungen:	T/T, Western Union, MoneyGram
Versorgungsmaterial-Fähigkeit:	100.000 Stück pro Monat

Kontakt

Ausführliche Produkt-Beschreibung

Produktname:	Abkühlungs-Magnetventil	Rohr-OD (mm):	7,94
Rohr-AD (Zoll):	5/16"	Öffnungsgröße:	5.8mm
Typ der Verkabelung:	Freie Anschlussleitungen	Betätigung:	Pilotbetrieb
Stromspannung:	24 VDC, 24 VAC, 110 VAC, 220 VAC	Anwendung:	Klimaanlage, Wärmepumpe, Eismaschine, Gefrierschrank, Kühlgerät usw.
Maximaler Betriebsdruck:	4.5 MPa
Hervorheben:	FDF6A refrigeration solenoid valve , FDF6A Two-Way Solenoid Valve , FDF6A58 Refrigeration Solenoid Valve

FDF6A FDF6A58 Sanhua Type Solenoid Valve FDF NC Series Valve For Heat Pump

Product Features of FDF series solenoid valves:

1. Direct operated or pilot operated, 2 way normally closed solenoid valve. Normally open type is available.

2. For use with non-corrosive refrigerant.

3. Compactly designed for use in small appliances produced in quantity such as room air conditioners, dehumidifiers, heat pumps and ice making machines.

4. Various piping configuration available.

Technical Data of FDF NC Series Solenoid Valve:

Model	FDF2A94	FDF2.5A06	FDF3A08	FDF4A10	FDF6A58	FDF8A21	FDF11A05	FDF13A07
Actuation	Direct	Pilot
Kv(m³/h)	0.08	0.2	0.26	0.3	0.56	1.29	2.4	3.44
Max. OPD (MPa)	3.4	3.4	3.4	3.4	3.4	2.8	2.8	2.8
Min. OPD (MPa)	0	0.01	0.01	0.01	0.01	0.01	0.02	0.02
MOP (MPa)	4.5
Normal Position	NC
Tube OD (inch)	1/4''	1/4''	5/16''	1/4''	5/16''	3/8''	1/2''	5/8''
Tube OD (mm)	6.35	6.34	7.94	6.35	7.94	9.52	12.7	15.88

Main Dimension of FDF NC Series Solenoid Valve:

FDF6A FDF6A58 Sanhua Type Solenoid Valve FDF NC Series Valve For Heat Pump 0

Model	Measurement (mm)
Model	L	L1	L2
FDF 2A 94	67	32	34
FDF 2.5A 08	85	38	38
FDF 3A 08	81	35	36
FDF 4A 10	81	35	38
FDF 6A 58	81	35	36
FDF 8A 21	114	62	62
FDF 11A 16	113	61	61
FDF 13A 12	114	62	62
